Daikin FTKU28BV1MF 1.0 HP Wall Mounted Deluxe Inverter Air-conditioner with Built-in Wifi Control & 3D AirflowSpecifications:Model nameIndoor unit: FTKU28BV1MFOutdoor unit: RKU28BV1MCapacity Rated (Min - Max):kW : 2.84 (1.08 - 3.40)Btu/h: 9,700 (3,700 - 11,600)Power supply : 1 phase, 220-240 V, 50 Hz (Power to indoor)Running current Rated (Min - Max) A : 3.37Power consumption Rated (Min - Max) W : 740 (260 - 1,200)CSPF (Wh/Wh): 5.60Energy rating: 5 starHeat insulation: Both liquid and gas pipingIndoor unitAirflow rate (cfm): 380Sound pressure levels - H / L / SL dB(A): 38 / 25 / 19Dimensions (H x W x D): 288 x 770 x 234mmUnit weight(kg): 9.0Outdoor unitRefrigerant: R32Sound pressure levels dB(A): 45Dimensions (H x W x D): 550 x 658 x 273mmUnit weight(kg): 24Piping connection:Liquid(mm):ø6.35Gas(mm):ø9.52Chargeless pipe length (m):7.5Maximum pipe length (m):20Maximum height difference (m):15Heat Exchanger Type: Hydrophillic Blue FinDaikin FTKU35BV1MF 1.5 HP Wall Mounted Deluxe Inverter Air-conditioner with Built-in Wifi Control & 3D Airflow Specifications:Model nameIndoor unit: FTKU35BV1MFOutdoor unit: RKU35BV1MCapacity Rated (Min - Max):kW : 3.55 (1.17 - 3.81)Btu/h: 12,100(4,000 - 13,000)Power supply : 1 phase, 220-240 V, 50 Hz (Power to indoor)Running current Rated (Min - Max) A : 4.38Power consumption Rated (Min - Max) W : 980 (280 - 1,250)CSPF (Wh/Wh): 5.60Energy rating: 5 starHeat insulation: Both liquid and gas pipingIndoor unitAirflow rate (cfm): 400Sound pressure levels - H / L / SL dB(A): 39 / 26 / 21Dimensions (H x W x D): 288 x 770 x 234mmUnit weight(kg): 9.0Outdoor unitRefrigerant: R32Sound pressure levels dB(A): 46Dimensions (H x W x D): 550 x 658 x 273mmUnit weight(kg): 26Piping connection:Liquid(mm):ø6.35Gas(mm):ø9.52Chargeless pipe length (m):7.5Maximum pipe length (m):20Maximum height difference (m):15Heat Exchanger Type: Hydrophillic Blue FinDaikin FTKU50BV1MF 2.0 HP Wall Mounted Deluxe Inverter Air-conditioner with Built-in Wifi Control & 3D AirflowSpecifications:Model nameIndoor unit: FTKU50BV1MFOutdoor unit: RKU50BV1MCapacity Rated (Min - Max):kW : 5.57 (1.76 - 6.21)Btu/h: 19,000 (6,000 - 21,200)Power supply : 1 phase, 220-240 V, 50 Hz (Power to indoor)Running current Rated (Min - Max) A : 6.99Power consumption Rated (Min - Max) W : 1,590 (420 - 2,200)CSPF (Wh/Wh): 5.60Energy rating: 5 starHeat insulation: Both liquid and gas pipingIndoor unitAirflow rate (cfm): 430Sound pressure levels - H / L / SL dB(A): 42 / 32 / 30Dimensions (H x W x D): 288 x 770 x 234mmUnit weight(kg): 9.5Outdoor unitRefrigerant: R32Sound pressure levels dB(A): 49Dimensions (H x W x D): 615 x 845 x 300mmUnit weight(kg): 37Piping connection:Liquid(mm):ø6.35Gas(mm):ø12.70Chargeless pipe length (m):7.5Maximum pipe length (m):30Maximum height difference (m):20Heat Exchanger Type: Hydrophillic Blue FinFeatures:Energy Saving with ECO+ ModeAn intelligent feature that ensures optimum energy consumption while fullfilling basic human comfort needs. Once activated, set temperature will be adjusted automatically to an eco-friendly level while limiting the maximum power consumption.Comfortable Airflow by 3D AirflowThis function combines vertical and horizontal auto swing to provide excellent air modulation in your room.It generates a rectangular motion of air throughout the room with improved motion of air draft coverage for an even faster and efficientcooling reach.Gin-Ion Blue FilterThis filter is treated with a positively charged silver ion, which efficiently draws viruses onto its surface and decomposes up to 99.9% in 2 hours. On top of that, this filter can deactivate bacteria and inhibit fungal growth on its surface to improve the quality of indoor air for a healthier lifestyle. The filter delivers consistent performance for around a year if filter is cleaned once every 2 weeks.Durable PCB (PCB Voltage Shield)Newly designed printed circuit board (PCB) for higher voltage surge tolerance. This PCB can easily handle large variations of voltage (130V-415V) therefore ensuring longer life span.GO DAIKINThis built-in network adaptor (AWM61A01) and the app turn a smartphone into a remote controller that can be used inside or outside the home. Together, they help to not only save energy and maintain comfort but also eliminate any worries of forgetting to turn off your air conditioner! (Certain app functions are optional.)Anti-Corrosion Treatment of Outdoor Heat Exchanger FinsThe outdoor unit’s heat exchanger fins are processed using a special anti-corrosion treatment. The surface is covered with a thin acrylic resin layer to enhance the fins’ resistance to salt corrosion. Higher Corrosion Resistance Gold Fin is available (Optional)
1.5HPPREMIUM INVERTERSMART CONTROLSMART CLEAN
Daikin FTKH35BV1MF 1.5 HP Wall Mounted Premium Inverter Air-conditioner with Built-in Wifi Control & Smart Clean
Features:
Smart Powerful + Operation
A smart feature that ensures maximum cooling performance delivered by engaging the indoor fan motor to run at maximum speed for 20mins. Utilizing the intelligence of sensor to detect human presence and to direct the airflow towards the detected human presense area for a faster and more efficient cooling.
Better Indoor Air Quality Using 3 Powerful Air Purification
Gin-Ion Blue Filter
This filter is treated with a positively charged silver ion, which efficiently draws viruses onto its surface and decomposes up to 99.9% in 2 hours. On top of that, this filter can deactivate bacteria and inhibit fungal growth on its surface to improve the quality of indoor air for a healthier lifestyle. The filter delivers consistent performance for around a year if filter is cleaned once every 2 weeks.
PM2.5 Dust Collection Filter
This filter removes PM2.5 particulate matter which is smaller than 2.5 micrometres (μm). PM2.5 is small enough to be breathed deep into our lungs.
Streamer Technology
High speed electrons are discharged that enable decomposition and removal allergens such as mould, mites, pollen and hazardous chemical.
Smart Ecomax
A smart feature that ensures maximum energy saving while fulfilling basic human comfort needs. Utilizing the intelligence of sensor to detect human presence in room while adjusting set temperature automatically while limiting the maximum power consumption.
GO DAIKIN
This built-in network adaptor (AWM61A01) and the app turn a smartphone into a remote controller that can be used inside or outside the home. Together, they help to not only save energy and maintain comfort but also eliminate any worries of forgetting to turn off your air conditioner! (Certain app functions are optional.)
Durable PCB (PCB Voltage Shield)
Newly designed printed circuit board (PCB) for higher voltage surge tolerance. This PCB can easily handle large variations of voltage (130V-415V) therefore ensuring longer life span.
Anti-Corrosion Treatment of Outdoor Heat Exchanger Fins
The outdoor unit’s heat exchanger fins are processed using a special anti-corrosion treatment. The surface is covered with a thin acrylic resin layer to enhance the fins’ resistance to salt corrosion. Higher Corrosion Resistance Gold Fin is available (Optional)
Specifications:
Model name
Indoor unit: FTKH35BV1MF
Outdoor unit: RKU35BV1M
Capacity Rated (Min - Max):
kW : 3.55 (1.17 - 3.81)
Btu/h: 12,100 (4,000 - 13,000)
Power supply : 1 phase, 220-240 V, 50 Hz (Power to indoor)
Running current Rated (Min - Max) A : 4.20
Power consumption Rated (Min - Max) W : 940 (280 - 1,250)
CSPF (Wh/Wh): 6.31
Energy rating: 5 star
Heat insulation: Both liquid and gas piping
Indoor unit
Airflow rate (cfm): 400
Sound pressure levels - H / L / SL dB(A): 40 / 28 / 22
Dimensions (H x W x D): 288 x 779 x 246mm
Unit weight(kg): 9.5
Outdoor unit
Refrigerant: R32
Sound pressure levels dB(A): 46
Dimensions (H x W x D): 550 x 658 x 273mm
Unit weight(kg): 26
Piping connection:
Liquid(mm):ø6.35
Gas(mm):ø9.52
Chargeless pipe length (m):7.5
Maximum pipe length (m):20
Maximum height difference (m):15
Heat Exchanger Type: Hydrophillic Blue Fin
DAIKIN Standard Inverter Air Conditioner - FTKF R32 - 2.0HP - FTKF50C【Specifications】Model : FTKF50CHorsepower : 2.0HPPower Supply : 1 phase 220-240Energy Rating: 4 Star【Features Highlight】√ Energy Saving R32 Refrigerant (Econo Mode)- This mode limits The maximum power consumption. It improves operating efficiency while fulfilling basic human comfort needs.√ Gin-Ion Blue Filter- This filter is treated with a positively charged silver ion, which efficiently draws viruses onto its surface and decomposes up to 99.9% in 2 hours. On top of that, this filter can deactivate bacteria and inhibit fungal growth on its surface to improve the quality of indoor air for a healthier lifestyle.*The filter delivers consistent performance for around a year if filter is cleaned once every 2 weeks.√ Low/High Voltage Shield (Super PCB)-All electrical components in indoor and outdoor units are designed for extreme durability. The printed circuit boards can easily handle large variations of voltage (150V-440V) and increase operation durability.√ Anti-Corrosion Treatment of Outdoor Heat Exchanger Fins- The outdoor unit’s heat exchanger fins are processed using a special anti-corrosion treatment. The surface is covered with a thin acrylic resin layer to enhance The fins’ resistance to salt corrosion.√ Easy Maintenance with Removable Drain Pan- The drain pan collects condensation from the indoor heat exchanger fins. Removable drain pans help to reduce the cleaning time.√ Smart Control - Built-In Wifi- This built-in network adaptor (AWM61A01) and the app turn a smartphone into a remote controller that can be used inside or outside the home.√ New Compact & Easy To Use Controller- Prominent temperature display- Real-time clock display- Easily accessible buttons+ Daikin Official Warranty Product (Extended 1 Year Warranty for All Parts for Limited Time Only)【What is in the box】1 set x FTKF50C / RKF50C-3WMY-LF - DAIKIN Standard Inverter Air Conditioner 2.0HP1 x Remote Control1 x Warranty Card
DAIKIN Standard Inverter Air Conditioner - FTKF R32 - 1.5HP - FTKF35C 【Specifications】Model : FTKF35CHorsepower : 1.5HPPower Supply : 1 phase 220-240 Energy Rating: 4 Star【Features Highlight】√ Energy Saving R32 Refrigerant (Econo Mode)- This mode limits The maximum power consumption. It improves operating efficiency while fulfilling basic human comfort needs.√ Gin-Ion Blue Filter- This filter is treated with a positively charged silver ion, which efficiently draws viruses onto its surface and decomposes up to 99.9% in 2 hours. On top of that, this filter can deactivate bacteria and inhibit fungal growth on its surface to improve the quality of indoor air for a healthier lifestyle.*The filter delivers consistent performance for around a year if filter is cleaned once every 2 weeks.√ Low/High Voltage Shield (Super PCB)-All electrical components in indoor and outdoor units are designed for extreme durability. The printed circuit boards can easily handle large variations of voltage (150V-440V) and increase operation durability.√ Anti-Corrosion Treatment of Outdoor Heat Exchanger Fins- The outdoor unit’s heat exchanger fins are processed using a special anti-corrosion treatment. The surface is covered with a thin acrylic resin layer to enhance The fins’ resistance to salt corrosion.√ Easy Maintenance with Removable Drain Pan- The drain pan collects condensation from the indoor heat exchanger fins. Removable drain pans help to reduce the cleaning time.√ Smart Control - Built-In Wifi- This built-in network adaptor (AWM61A01) and the app turn a smartphone into a remote controller that can be used inside or outside the home.√ New Compact & Easy To Use Controller- Prominent temperature display- Real-time clock display- Easily accessible buttons+ Daikin Official Warranty Product (Extended 1 Year Warranty for All Parts for Limited Time Only)【What is in the box】1 set x FTKF35C / RKF35C-3WMY-LF - DAIKIN Standard Inverter Air Conditioner 1.5HP1 x Remote Control1 x Warranty Card
DAIKIN Standard Inverter Air Conditioner - FTKF R32 - 1.0HP - FTKF25C 【Specifications】Model : FTKF25CHorsepower : 1.0HPPower Supply : 1 phase 220-240 Energy Rating: 4 Star【Features Highlight】√ Energy Saving R32 Refrigerant (Econo Mode)- This mode limits The maximum power consumption. It improves operating efficiency while fulfilling basic human comfort needs.√ Gin-Ion Blue Filter- This filter is treated with a positively charged silver ion, which efficiently draws viruses onto its surface and decomposes up to 99.9% in 2 hours. On top of that, this filter can deactivate bacteria and inhibit fungal growth on its surface to improve the quality of indoor air for a healthier lifestyle.*The filter delivers consistent performance for around a year if filter is cleaned once every 2 weeks.√ Low/High Voltage Shield (Super PCB)-All electrical components in indoor and outdoor units are designed for extreme durability. The printed circuit boards can easily handle large variations of voltage (150V-440V) and increase operation durability.√ Anti-Corrosion Treatment of Outdoor Heat Exchanger Fins- The outdoor unit’s heat exchanger fins are processed using a special anti-corrosion treatment. The surface is covered with a thin acrylic resin layer to enhance The fins’ resistance to salt corrosion.√ Easy Maintenance with Removable Drain Pan- The drain pan collects condensation from the indoor heat exchanger fins. Removable drain pans help to reduce the cleaning time.√ Smart Control - Built-In Wifi- This built-in network adaptor (AWM61A01) and the app turn a smartphone into a remote controller that can be used inside or outside the home.√ New Compact & Easy To Use Controller- Prominent temperature display- Real-time clock display- Easily accessible buttons+ Daikin Official Warranty Product(Extended 1 Year Warranty for All Parts for Limited Time Only)【What is in the box】1 set x FTKF25C / RKF25C-3WMY-LF - DAIKIN Standard Inverter Air Conditioner 1.0HP1 x Remote Control1 x Warranty Card
Features
iECO Mode (Energy Saving)
Smart Control (Control Your AC, Anytime and Anywhere)
Built-in WiFi Control
Gear Shift
Air Magic (Millions of positive and negative ions eliminate up to 99% of bacteria and viruses.)
Cold Catalyst Filter
4 Star Energy Rating
Provide Fresh and Clean Air to the Room Inside cleaning works inside of an indoor unit by removing moisture, and releases nanoeTM X to inhibit bacteria and viruses, while the improved anti-dust cross flow fan prevents dust adherence for better performance. INSIDE + *2 Testing Organisation: Protectea,Ltd Test subject: Bacteria (Escherichia coli CLEANING NBRC33011 and Virus (Escherichia coli Phage QB NBRC20012) Tested time: 2.5 hours Test Result: 99% inhibited (compared to non-operation) Test
Provide Fresh and Clean Air to the Room
Inside cleaning works inside of an indoor unit by removing moisture, and releases nanoeTM X to inhibit bacteria and viruses, while the improved anti-dust cross flow fan prevents dust adherence for better performance.
INSIDE +
*2 Testing Organisation: Protectea,Ltd Test subject: Bacteria (Escherichia coli
CLEANING NBRC33011 and Virus (Escherichia coli Phage QB NBRC20012) Tested time:
2.5 hours Test Result: 99% inhibited (compared to non-operation) Test
Provide Fresh and Clean Air to the Room
Inside cleaning works inside of an indoor unit by removing moisture, and releases nanoeTM X to inhibit bacteria and viruses, while the improved anti-dust cross flow fan prevents dust adherence for better performance.
INSIDE +
*2 Testing Organisation: Protectea,Ltd Test subject: Bacteria (Escherichia coli
CLEANING NBRC33011 and Virus (Escherichia coli Phage QB NBRC20012) Tested time:
2.5 hours Test Result: 99% inhibited (compared to non-operation) Test
Free installation with Term and conditions.
1. Cover Basic installation
2. Up to 10ft electrical cabling and insulation.
3. Up to 15ft drainpipe
4. Extra requirement bare by customer.
5. Free installation campaign period (1-7 September only)
6. Full & details term & conditions please refer to last product image.
