Flame failure cuts off gas supply for your safety.
High power burner is ideal for stir-frying.
Wide rotary knob turns 225° for a flexible flame.
Safety Film prevents shattering for safer cooking.
Blue flame burns efficiently to lower energy cost.
Durable, easy-to-clean tempered glass surface.
Safety shut-off
The flame failure safety device automatically cuts off the gas supply if the flame goes out during cooking. This means you can use your appliance at the lowest power without worrying about the flame extinguishing and leaking gas.
High power. Intense flavour.
The high-power burner provides intense heat and a steady flame exactly when you need it most. This is perfect for stir-frying when a very high temperature is needed to lock in the texture and flavour of crunchy vegetables or fried rice.
Flexible flame control
The wide rotary knob turns to a maximum 225° for flexibility at your fingertips, to give you precise flame control with ease for perfect results every time.
Extra protection safer cooking
The Safety Film holds glass fragments together if it breaks, reducing the risk of sharp pieces spreading. This ensures a safer kitchen environment during impacts or high heat, improving safety for you and your family.
Lower your utility bill
The blue flame burns efficiently to turn up the flavours faster, whilst also keeping your energy costs down.
Effortless cleaning
The flat tempered glass surface makes it easier to clean burnt-on grease and grime to speed up the cleaning process after cooking.
Features
Blue flame
One hand ignition
Flame failure device
Wok burner
Safety Film
No. of cooking zones : 2
6mm Black Tempered Glass Surface
L:5.0 ; R:5.0 ; M:2.0 (kW) Burner Power
Vortex Flame burner
Cast Iron Pan Support
With Flame Failure Device(Safety)
With Battery Ignition
Support LPG Gas
('M flame only available for VISTA 3B)
Glass Lifetime Warranty (*Term And Conditions Apply)
5 years gas hob warranty
18 months Standard Warranty
Size: W78cm x D46cm
Technical Overview
Cooktop type
Gas cooktop
Total number of positions that can be used at the same time
3
Flame select
No
Type of frame
Design frame
Basic surface material
Tempered glass
Material of pan supports
Matt enamel
Gas type preset
Liquidgas G30,31 28-30/37 mbar
Induction:
Touch control system
Pause function
9 Speeds control at ease
Power supply : 220 – 240V – 50Hz
Standby electric : 2W
Cooking range : 2000W
Timer : 1~240 minutes
Auto cut-off : 60 minutes
Gas Stove:
Flexible Base (can fit in variety of built-in hole)
Sealed burner for easy cleaning
Has up to 5.2kW heat intensity
Top-notch brass burner
Fast ignition technology
Built-in flame failure device (Auto gas cut-off within 10 secs)
Heat resistance tempered glass
Battery operated auto-ignition
Safety vavle
Gas type : LPG
CAUTION: Please ensure that the burner cap is placed securely and evenly to prevent any gas leaks and potential fire hazards.
Operation:
1) Pressed and hold the knob for 3 – 5 seconds before turning it.
2) After flame ignites, keep pressing the knob for 5 more seconds before releasing it to prevent the flame from going out.
Remark: When either of the knobs is pressed, both ignition pins will light up, indicating that the gas is ready to ignite. However, the gas supply for each burner is separate, so only the burner that has been turned on will ignite and produce a flame.
