Key Features
Alpha SMART Auto Test
Automatically runs a self-test on all internal components before showers to detect electrical leakages and ensure utmost safety.
Line Fault Indicator
Detects and alerts of any false electrical connections with a red/ green indicator light.
55 Watt DC Pump
Enhances your showers with more power while maximizing energy and water saving.
Pump Activator
Amplifies water pressure to ensure voluminous showers even at low inlet flows.
Pump Control
Fine-tune your shower’s water pressure to your exact liking.
Dual Safety Thermal Protection
Automatically breaks off power supply if there is an abnormal rise in shower temperatures.
Tier 1: 55°C Auto Cut-offTier 2: 85°C Overheat Cut-out
Double Relay ELSD
Immediately cuts off both live and neutral current flows in the event of an electrical surge.
IP25 Splash Proof Casing
Protects your heater’s internal components from any water seepage.
Nylon Fibre Internal Construction
A strong and durable non-conductive material that provides insulation to your heater
Key Features
4.5kW Super power
Enhanced heater performance for fast water heating.
Canvas Shine Texture
Utilising 3-layer etching technology and detailed hue matching, the heater bodies a stunning shine texture that mimics the ridges of canvas fabric.
Specification
Technical Specification
Model
WES7 BASIC
Colours Available
Blue Linen, Gold Cotton, White Chiffon, Black Canvas
Pump Type
DC Pump
Pump Rating
55W
Noise Level
<50dB
Heater Power Rating
4.5kW, 240V ~ 50Hz
Water Connection
15mm (1/2" BSP), Single Point System
Operating Condition
Open Outlet
Protection Against Electric Shock
Class 1
Water Temperature Control
Electronics
Degree of Protection
IP25
Minimum Flow Rate
2 Liters / Minute
Minimum Pressure
20kPa (0.2 bar / 2.9 psi)
Maximum Inlet Pressure
0.38MPa (3.8bar/55psi)
Heater Dimension
245mm (W) x 326mm (L) x 85mm (H)
Nett Weight
1.8kg
Power: 4200W
Dual Copper Heating Tube
DC Inverter Silent Pump
Shock Proof
Bubble Elimination Technology
Solid Structure Tank
4D AI Thermostat System
Extra Hot
Anti-bacterial Technology
Multi-functional Shower Head
Accurate Temperature Display
Minimum Inlet Pressure (MPa/kPa/bar): 0.03/30/0.3
MaximumInlet Pressure (MPa/kPa/bar): 0.3/300/3
Minimum Flow Rate: 1.5L / min
Product Dimension (WxDxH): 230 x 81 x 380 (mm)
Product Weight: 2.1kg
2 Years General Warranty
6 Years Heating Element
5 Years DC Inverter Silent Pump
Model: Haier DC Inverter Silent Pump Rain Shower Water Heater EI42E-FP3B(MY) (Navy Blue)
Highlight
*Product Name: RWH-S391D-BCB
Product Overview:
Series: FLUSSO
Color: CARBON BLACK
Power Rating: 3.6kW 240V 50Hz
Min. Water Pressure: 0.2 bar
Min. Water Flow Rate: 2 LITRE/ MIN
Inlet/Outlet Water Connector: ø 15mm (1/2"" BSP)
Temperature Control: Stepless Electronic
Pump Type: Inverter DC Silent Pump
Specifications :
Series : Cubo
Color : Sand Black
Power Rating : 3.8kW, 240V, 50Hz
Min. Water Pressure : 0.2bar / 20kPa / 2.9psi
Min. Water Flow Rate : 1.6 Litre/min
Inlet / Outlet Water Connector : Ø15mm
Temperature Control : Stepless Electronic
Product Dimension WxDxH : 236 x 87 x 259 (mm)
Water Heater Nett Weight : 1.2kg
Rated Power : 3.6 kW
Power Supply : 240 V , 50 Hz
Protects against fire & electrical hazards with 9 safety features
Protects against bacteria with Ag+ Crystal Material
Spa-like shower with U-Mode comfortable temperatures
Pre-set personalised profiles with U-Memory
Gentle & comfortable water texture with 3-way shower head
Basic Specification
PUMP/ NO PUMP - DC Pump
TYPE - LCD type
Power Supply - 240 V, 50 Hz
Rated Power - 3.6 kW
Dimensions (h x w x d) mm - 385 x 210 x 78
Main Unit Weight (kg) - 2.8 kg
Body Colour - Dark Metallic Navy
Standard Regulation - SURUHANJAYA TENAGA (Safety)
ELB indication method - "SAFE" word on LCD screen
Water Stop System - One Push On/Off Switch
Water Pressure:
Minimum - 0.05 kgf/cm²
Maximum - 3.87 kgf/cm²
9 Safety Features:
1. Water Splash Prood Case Cover - IEC 60529 (IP2X)
2. Durable Copper Heater Unit - Yes
3. On Push On/Off Switch - Yes
4. Insulated Structure - Yes. IEC 60529 (IP2X)
5. Built-in Earth Leakage Breaker (ELB) - Yes
6. Water Flow Sensor - Yes
7. Non-flammable Material Cover - Yes
8. Manual Reset Thermostat - Yes
9. Auto Thermal Cut-off - 55ºC
Comfort Features:
U-memory
U-mode - Yes (Warm Up, Cool Down, Hot & Cool Modes)
On/Off Pump function - Yes
Ag+ Antibacterial material - Yes
3-way Shower - Normal, Wide, Spot
9 safety features
Ag+ Crystal Material
3-way shower head
Protects against fire & electrical hazardsTo ensure the utmost safety, we developed technologies and designs that provide protection for numerous hazards such as water & heat resistance, as well as preventing fire, burn, and electric shock.Protects against bacteriaCommonly touched areas especially shower head, one push on/off switch, filter body, power control knob are made with the Ag+ Crystal Material to protect against bacteria.Gentle & Comfortable Water TextureEasily switches between shower textures by moving the lever left and right with one hand. The improved shower head design creates a shower effect that feels good on the skin. Comes with 3 different water textures - ‘normal, wide, and spot’ for a spa-like shower at home.SpecificationsGeneral InformationPUMP/ NO PUMPNon PumpTYPENon LCD type (Analogue)Power Supply240 V, 50 HzRated Power3.6 kWWater Pressuremin. 0.10 kgf/cm² ; max 3.87 kgf/cm²Dimensions (h x w x d) mm385 x 210 x 78Main Unit Weight (kg)1.5 kgBody ColourSkin SilverStandard RegulationSURUHANJAYA TENAGA (Safety)ELB indication methodRed ELB LightWater Stop SystemOne Push On/Off Switch9 Safety FeaturesWater Splash Prood Case CoverIEC 60529 (IP2X)Durable Copper Heater UnitYesOn Push On/Off SwitchYesInsulated StructureYes. IEC 60529 (IP2X)Built-in Earth Leakage Breaker (ELB)YesWater Flow SensorYesNon-flammable Material CoverYesManual Reset ThermostatYesAuto Thermal Cut-off55ºCComfort FeaturesU-memory-U-mode-On/Off Pump function-Ag+ Antibacterial materialYes3-way ShowerNormal, Wide, Spot
Features
Your Everyday Shower Clean & Worry-free
Leave your worries out of the bathroom. Panasonic U Series is built with 9 safety features that help to prevent electric shocks, fire & burn. The shower panel is water-splash proof to protect the internal components, while the Ag+ Crystal Material prevents the growth of bacteria for a more carefree shower experience.
Keeping You Safe & Clean
Protects against fire & electrical hazards
To ensure the utmost safety, we developed technologies and designs that provide protection for numerous hazards such as water & heat resistance, as well as preventing fire, burn, and electric shock.
Protects against bacteria
Commonly touched areas especially shower head, one push on/off switch, filter body, power control knob are made with the Ag+ Crystal Material to protect against bacteria.
Relax & Refresh with Comfortable Shower
Gentle & Comfortable Water Texture
3-way Shower Head
Normal
Mix-spray combining soft yet revitalising water texture, for a gentle and relaxing shower.Cleanse your body with soothing droplets for a wake-up call before you take on the day.
Wide
Intense jets of fine micro-droplets to cleanse your body from lethargy. Take relaxation up a notch after a long day, to ease your body into resting mode.
Spot
Concentrated spray that mimics the feeling of a massage. The targeted spray is ideal for relaxing the muscle and tensed areas, perfect for after an intense workout or stressful day.
Modernly Sleek
The U Series is designed with simple, high-quality, and iconic asymmetrical designs that effortlessly fit into every bathroom.
Step into a worry-free shower designed for the whole family, complete with safety and hygiene features to keep everyone safe. The Made in Japan DC Pump ensures quieter operation and a strong water flow for an enjoyable everyday shower.
PRODUCT FEATURES:
Rated Power : 3.6 kW
Power Supply : 240 V , 50 Hz
Protects against fire & electrical hazards with 9 safety features
Protects against bacteria with Ag+ Crystal Material
Adjustable water texture with 3-way shower head
Strong water flow and low-noise operation with Made In Japan DC Pump
Rated Power : 3.6 kW\nPower Supply : 240 V , 50 Hz
Protects against fire & electrical hazards with 9 safety features
Protects against bacteria with Ag+ Crystal Material
Adjustable water texture with 3-way shower head
